Electrical Separation Shaver Socket Diagram. The front of a shaver supply unit is marked with the rated voltage (s) and with the symbol shown left. Shaver sockets can be installed either by connecting to a ring main with junction box, or from an earthed lighting socket.

17th Edition Part 4 from www.slideshare.net

Electrical separation 413.1.2/.3 & 418.3. The first part of this is to cut the correct size hole in the wall, provided the position for the shaver socket has been marked. Shaver sockets are protected by electrical separation;
